The CUP-15 series alcohol extraction system provides the ability to extract and target botanical compounds from a diverse plant species. This unique extraction technology can isolate specific botanical compounds through programmable sequences, effectively targeting the desired separation.


CUP-15

KEY FEATURES

Artboard 13.png

The system combines closed-loop, cold alcohol extraction with mechanical centrifugation which ensures high-purity extractions.

centrifuge-ethanol-extraction-botanical-

CLOSED LOOP

Artboard 16.png

Improves the yield and quality of your extraction cycle using a custom designed automated control logic.

IMPROVED YIELD

TECHNICAL SPECIFICATIONS

​​​​​PRODUCT FEATURES

  1. UL listed Electronics C1D2 for Hazardous Locations

  2. 304 and 316L Sanitary Stainless Steel Construction

  3. Rated Low Temp Conditions (-40C)

  4. Tempered and Reinforced Sight Glass

  5. Vacuum Jacket Insulation

  6. Bi-Directional Agitation

  7. Auto/Manual Controls

​

ELECTRICAL

  1. PHASE – 1

  2. VOLTAGE – 230

  3. AMPS – 30



PHYSICAL

  1. SPACE REQ. (FT) – 8 X 5 X 4.5

​

MATERIAL PER BATCH

  1. 10 Lbs – 15 Lbs

​

AVERAGE RUN TIME

  1. 10 – 15 Mins

​

ALCOHOL USAGE PER RUN

  1. 13 – 15 Gallons
